HPG Heavy H-beam Shot Blasting Series HPG2512
Quick Detail:
| Name | Shot blasting machine | Model | HPG2512 |
| Industry used | Forging, Foudry, Casting | Brand | CMC |
| Machine Type | Automatic digital control | Color | Customrized |
| After-sales service provided | Engineers availabe to service machiney overseas | Cleaning process | Steel shot |
Description:
The shot blasting machine of this series is a kind of multifunctional shot blasting equipment of large scale welding structure, H-beam, space grid, steel plate. It can clean large “I” shape steel, heavy welded steel structure, belonging to a roller continuous operation equipment. This equipment selects of the world’s advanced single disc curve blade efficient shot blasting machine and it use the world’s advanced single disc curve blade efficient shot blasting machine, it can shot off high speed dense projectile hitting steel every parts in the primitive state to make stereo and all-around clean.
Applications:
Typically used in situations requiring the blasting of H beams, Angles and flats, steel plates, steel pipes, square tube, box iron at a high rate. Steel preprocessing machine line mainly used for construction machinery, mining machinery, chemical equipment, pressure vessel, transportation vehicle, ship and bridge and architectural profile industry etc. It used for improve the surface quality and resistance to corrosion.
· removing the rust, mill scale , weld spatter and other contaminants of work piece
· achiving a fine surface with certain roughness
· reducing the internal stres of work piece
· improving the ability of adhesion and anticorrosion
· improving the steel quality
· prolong the service life of work piece
Specifications:
| Model
Technical parameters | HPG2512 | HPG2515 | HPG3020 |
| Effective cleaning height(mm) | 2500 | 2500 | 3000 |
| Effective cleaning widthness(mm) | 1200 | 1500 | 2000 |
| Chamber body size of feeding(mm) | 2530×1400 | 2530×1700 | 3030×2200 |
| Length of cleaning workpiece(mm) | 3000-18000 | 3000-18000 | 3000-18000 |
| Thickness of cleaning steel plate(mm) | 5-80 | 5-100 | 5-120 |
| Cleaning material specification | 2500-1200 | 2500-1500 | 3000-2000 |
| Roller conveyor speed ( frequency stepless speed control(m/min) | 0.5-5.5 | 0.4-4 | 0.5-5.5 |
| Blast volume(kg/min) | 12×220 | 12×220 | 14×220 |
| Steel first loading(kg) | 6500 | 7000 | 8000 |
| Ventilation rate(m3/h) | 22000 | 25000 | 33000 |
| Depth below the ground(mm) | 2260 | 2260 | 2930 |
| Overall dimensions (mm) | 37820×4600×9500 | 40820×5000×9600 | 40978×5500×11090 |
| Total power (kw) | 201 | 208.5 | 253 |
Detailed picture:
